EXCELL PRECISION CO., LTD
02005302 ZSME300000237 34
NOTE 1 The users can set up the different weight UNITS in various orders according to their
preference, and the amount of the chosen weight UNITS can be up to 5
(a) (b) (c) (d) (e) (f)
(a) ⇒ The first weight UNITS (only “kg”, “g”, or “lb” are available to choose from. Please select one of
the parameters 0, 1, or 2)
(b) ⇒ The second weight UNITS (select one of the parameters described below)
(c) ⇒ The third weight UNITS (select one of the parameters described below)
(d) ⇒ The fourth weight UNITS (select one of the parameters described below)
(e) ⇒ The fifth weight UNITS (select one of the parameters described below)
(f)
⇒ The amount of the weight UNITS selected (select one of parameters 1 ~ 5)
The description of the parameters
0
⇒ kg (Decimal system) 5 ⇒ oz (Decimal system)
1 ⇒ g (Decimal system) 6 ⇒ GN (Decimal system)
2 ⇒ lb (Decimal system) 7 ⇒ dwt (Decimal system)
3 ⇒ reserved 8 ⇒ ct (Decimal system)
4 ⇒ lb, oz (hexadecimal)
For example:
Choose “kg” & “lb” (two weight UNITS). NOTE the scale is calibrated using “kg” weights and key
in 020002
NOTE 2
Enter the maximum capacity of the scale, total 6 digits (not including 9d)(d=division)
(g) (h) (i) (j) (k) (l)
For example:
15.000 kg ⇒ key in 015000
1500.0 g
⇒ key in 015000
6.000 lb
⇒ key in 006000
NOTE 3
Set the minimum division and decimal point position to determine the display
resolution
(m) (n) (o) (p) (q)
Division = m * 10
-n*q
, m = base value, n = numbers of decimal point, q = multiplication
factor
(m)
⇒ Division base value, select 1, 2, or 5
(n)
⇒ The number of decimal places (0 ~ 5)
For example: 15.000 kg ⇒ enter 3, 1500.0 g ⇒ enter 1, 6.000 lb ⇒ enter 3
(o) ⇒ range setting (select one of parameters 0, 1, 2, or 3)
For example: 0, 1 ⇒ full segment range, 2 ⇒ 2 segment range (divided at 1/2 of the full scale),
3
⇒ 3 segment range (divided at 1/6 of the full scale & 2/3 of the full scale)
To Next Page
