Chap 2 Installation & Connection
Before Installation
For easy and quick installation and connection, it is strongly recommended that the user read
and follow the following instruction carefully so as not to damage the system accidentally by
incorrect operation.
2.1 System Configuration
This system capacity smallest is 208, biggest is 416.
This series PABX including basical series CS (plastic covers) and TS (metal covers), and
enhancement series CS+ (plastic covers) and TS+ (metal covers); CS and TS same functions,
CS+ and TS+ same functions. And TS+ series can be expanded wireless terminal board.
Model
CS /TS
CS+/TS+
CS208
TS208
CS308
TS308
CS312
TS312
CS416
TS416
CS+208
TS+208
CS+308
TS+312
CS+312
TS+312
CS+416
TS+416
CO Line Ports
2
3
3
4
2
3
3
4
Exts. Ports
8
8
12
16
8
8
12
16
DISA
10s one paragraph
20s three paragraphs
Music On
Holding
Piano music, external music input on
holding is optional
11 chord melody music, external music
input on holding is optional
Caller ID
External line caller ID
Transfer & internal caller ID
Please according to the capacity and functions of your machine when install
and program the system.
