Operating the Optical Switch
Optical Switch 43
Connecting RTUe-9120 External Switches to the RTU-2 Unit
6. Connect the first port of the FTBx switch to the common port of the first
RTUe-9120 switch.
Note: Since the RTUe-9120 switch is equipped with unpinned MPO ports (two
rows of eight fibers each), you will need a patchcord with a pinned MPO
connector.
7. Repeat step 6 with the remaining switches that you want to connect to
the RTU-2 unit.
