Remote Control Commands
Variable Attenuator 89
Specific commands-Quick Reference Command Tree
Specific commands-Quick Reference
Command Tree
Command
Parameter/
Response
Description
ATT
a,
b
<±99.99 [DB] | MIN|MAX> set attenuation
ATT? (± 999.99) obtain attenuation
CAL
a,
b
<±99.99> set offset
CAL? (± 999.99) obtain offset
D
b
<0|1> activate shutter
D? (0|1) obtain shutter state
DISP DIMM <LO | HI | OFF> adjust display
intensity
DIMM
?
<LO | HI | OFF> obtain display
intensity
F
a, b
<1|2> set fiber type
F? (1|2) obtain fiber type
INP ATT
a
<±99.99 [DB] | MIN|MAX> set attenuation
ATT? (± 999.99) obtain attenuation
OFFS
a
<±999.99 [DB]> set a reference
value
DISP set ref. to display
OFFS? (±999.99) read reference
value
STEP 0.01<step<50 set step
CATA
?
list of available steps obtain step list
