Operating Your Variable Attenuator
Variable Attenuator 49
Operating the Shutter
Operating the Shutter
The optical shutter is an electro-mechanical device which, when activated,
totally blocks light transmission.
To block light transmission:
Use the Shutter button to turn the shutter on or off. When the shutter is
activated, Shutter On appears in the lower right portion of the display.
CAUTION
Using the shutter continuously at a rate of one cycle per three
seconds may damage the instrument permanently or seriously
reduce its life cycle.
VARIABLE ATTENUATOR
FVA-3100
Offset
ENTER
Abs Up Shutter
Ref
λ
Down Attenuation
Program
Setup
Arrow buttons for
menu navigation and
parameter setting
Shutter control
Step
In Monitor Out
Shutter
