Getting Started with Your Unit
26 OTH-7000
Connecting Your Unit to a Power Source
5. Crimp each power lead (maximum 14 AWG) with a terminal (ferrule)
or tin each of them. Unscrew the four screws (shown in gray) located
at the top of the terminal block.
6. Pair the power leads with the appropriate power terminal for each of
the feed, respecting the polarity as indicated on the terminal block.
