Maintenance
ReplacingtheDischarge
Deector
ServiceInterval:Asrequired
DANGER
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator’sor
bystander’sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyouinstall
amulchplate,dischargedeector,orgrass
collectionsystem.
1.Toremoveadamagedorworndischargedeector,
liftthelegofthespringwiththeloopoutofthe
notchinthedischargedeectorandslidethe
rodoutofthedischargedeectorbrackets,and
dischargedeector.
2.Toinstallnewdischargedeector,orientthe
springontherodasshownin
Figure13.Slidethe
rodthroughthefrontdischargedeectorbracket,
dischargedeector,andreardeectorbracket.
Figure13
1.Rod4.Mowerdeck
2.Spring5.Dischargedeector
bracket
3.Dischargedeector
6.Assembledview
3.Hookthebentendoftherodaroundthefront
dischargedeectorbrackettoretainitfrom
slidingout.Placethelegofthespringwiththe
loopinthenotchinthedischargedeectorto
holdthedischargedeectorinthedownposition
(see
Figure13).
Important:Thedischargedeectormustbe
springloadedinthedownposition.Liftthe
deectoruptotestthatitsnapstothefull
downposition.
CheckSafetyInterlock
System
ServiceInterval:Beforeeachuseordaily
1.ForElectricStartUnitsOnly:Checkstarting
circuit.Startershouldcrankwith:Operator
PresenceControlleversdepressed,speedcontrol
leverinneutral,andPTOdisengaged.
TrytostarttheenginewithOPClevers
disengaged,speedcontrolleverinneutraland
PTOdisengaged–startermustnotcrank.
