AvediaStream e2635/e3635 and e2655/e3655 Encoders V1.1
Administrator’s Guide 37
To specify the audio input:
1. Click Source.
2. Choose an option from the Audio Input drop down list.
3. Click the Apply button.
SDI Audio Group and Channel
When Embedded is selected, the module extracts the audio from the SDI stream. Configure
the Group and Channel settings to select the required audio from the 8 possible stereo pairs.
The default setting is Group 1 and Channels 1/2.
To specify the audio group:
1. Click Source.
2. Choose an option from the Audio Group drop down list.
3. Choose an option from the Audio Channel drop down list.
4. Click the Apply button.
