AvediaStream e2635/e3635 and e2655/e3655 Encoders V1.1
Administrator’s Guide 39
To select and configure CBR:
1. Click Encoding.
2. Click the Bit Rate Mode drop down list to select Constant.
3. Click the Bit Rate drop down list to select a value from 128 kbps to 20 Mbps
4. Click the Apply button.
To select and configure VBR :
1. Click Encoding.
2. Click the Bit Rate Mode drop down list to select Variable.
3. Click the Average Rate drop down list to select a value from 128 kbps to 20 Mbps.
4. Click the Maximum Rate drop down list to select a value from 128 kbps to 20 Mbps.
5. Click the Apply button.
Aspect Ratio
To specify the aspect ratio:
1. Click Encoding.
2. Click the Aspect Ratio drop down list to select Unchanged, 4:3 or 16:9.
3. Click the Apply button.
Frame Rate
Lowering the frame rate enables you to reduce the bandwidth required in the output stream.
However, this may affect the picture quality on fast action content. The default is 50 Hz.
To specify the frame rate:
1. Click Encoding.
2. Click the Frame Rate drop down list to select Unchanged, or a value between 60 Hz and
12.5 Hz.
3. Click the Apply button.
Output Resolution
Lowering the resolution to suit the output device enables you to reduce the bandwidth required
in the output stream. However, this may affect the picture quality on high resolution displays.
The default is No Scaling.
To specify the output resolution:
1. Click Encoding.
2. Click the Output Resolution drop down list to select No Scaling, or a value lower than
the input stream.
3. Click the Apply button.
Audio Configuration
You can select the encoding standard and bit rate for the output stream. The e2635/e3635
default Audio Standard and Bit Rate settings are MP2 and 64kbps. The e2655/e3655 default
Audio Standard and Bit Rate settings are MP2 and 192kbps.
