INSERT EXTRACTION5.6.
The extraction of the Comfort allows to load pellets inside the feed-
box and to perform routine maintenance, (cleaning the ash pipe
at the end of the year) or extraordinary maintenance (replacement
of mechanical parts if the product should break). Maintenance
operations must be performed when the insert is o , with
the plug disconnected from the socket and by an authorised
technician and/or the manufacturer's technical after-sales
assistance.
Follow this procedure to extract the insert:
Take the relevant Allen wrench and insert it in the screw (see
previous paragraph).
Turn the wrench anti-clockwise.
Using the relevant re irons, pull the machine towards
yourself until it blocks automatically.
gure 25
HOT AIR DUCTING6.
The pipe destined for ducting the hot air must have an internal
diameter of 80 mm, be insulated and protected from heat loss.
The length must not exceed 2 metres.The relative pipes used
for ducting the hot air must be installed by qualified staff
and/or the manufacturer's after-sales technicians
TOSCA PLUS EMMA PLUS6.1.
The Tosca Plus also has 2 pipes placed in the rear for ducting hot air.
The Tosca Plus also o ers the possibility to decide where to aim the
hot air ow thanks to two gate valves moved by 2 lever positioned
inside the pellet tank, which must be activated via the re irons
supplied (see gures below).
gure 26 gure 27 gure 28
ELISIR6.2.
The “Elisir” model can be ducted at the rear of the machine, laterally
and from above.
gure 29
gure 30
gura 31
COMFORT PLUS6.3.
Attention: for this product it is mandatory to duct the hot air
gure 32
gure 33
