INSERTS INSTALLATION
9
ENGLISH
withdrawn from outside through a pipe). The air ow can also be
obtained from an adjacent room, as long as the ow takes place
freely through permanent openings communicating with the
outside.
The adjacent room, with respect to the installation room, must not
be put in depression with respect to the external environment by
means of reverse draught caused by the presence of another used
appliance or intake device in such room. The permanent openings
in the adjacent room must comply with the above-described
requisites. The adjacent room cannot be set up as garage, storage
for combustion material or activity with danger of re.
INSULATION, FINISHINGS, 4.5.
COVERING AND SAFETY
RECOMMENDATIONS
The coverings, independently from the materials from which they
are made, must constitute a self-supporting construction with
respect to the heating block and not be in contact with it.
The cross members and nishings in wood or combustion
materials must be positioned outside the hearth radiation area or
adequately insulated.
If coverings in combustion material or sensitive to heat exist in the
space above the generator, an insulating and non combustible
protection diaphragm must be inserted.
Elements in combustible or in ammable material like wooden
furniture, curtains, etc., directly exposed to the hearth radiation,
must be positioned at a safe distance. The appliance installation
must guarantee easy access for cleaning the appliance itself,
discharge gas pipe and ue.
NATIONAL, REGIONAL, 4.6.
PROVINCIAL AND TOWN COUNCIL
REGULATIONS
It is necessary to bear in mind all laws and national, regional,
provincial and town council Standards present in the country the
appliance has been installed.
INSERTS INSTALLATION5.
The model is supplied with a sliding base in iron, which allows
it to be installed in a pre-existing chimney, allowing it to be
extracted, with the machine o , easily both for feeding pellets
into the tank and for any maintenance or end of season cleaning.
If there is no pre-existing ue, one can be built using the insert-
holder pedestal (optional kit); in fact, the latter xes the insert
to the oor.
Image key: primary air (A), combustion gas discharge (B), frame
(C), sliding base (D), ducting (F)
C
A
B
D
Comfort Maxi
gure 11
A
B
D
C
F
Comfort Plus
gure 12
A
B
D
C
Comfort Mini/Mini Chrystal/P80
gure 13
INSERT COMPARTMENT MINIMUM 5.1.
MEASUREMENTS
For correct functioning of the insert, during construction of the ue the
measurements between the insert and internal walls of the ue must
be respected. From the clearance measurements of the stove given in
the technical features, it is necessary to consider at least 50 mm of air in
the upper part and on the 2 sides. The ue outlet pipe must always
maintain a minimum distance of 50 mm from in ammable parts.
COMFORT/P80
50mm
50 mm
50 mm
gure 14
