Extraflame DIVINA Use And Maintenance Manual

40
FUEL
LACK
FUEL
EXCESS
Increase the percentage value of 5 points and test the stove with the new
calibration. If the problem is reduced but not solved, increase of further 5
points. Repeat the operation up to the solution of the problem. In case it is
not solved, contact the office of technical assistance.
Reduce the percentage value of 5 points and test the stove with the new
calibration. If the problem is reduced but not solved, decrease of further 5
points. Repeat the operation up to the solution of the problem. In case it is
not solved, contact the office of technical assistance.
Adjustment table
4.6 LANGUAGE MENU
This menu allows to select the language of the menu. Currently it is available the ITALIAN version only
5 ALARMS DESCRIPTION
We provide here below the table of alarms which may occur :
AlarmType of problem Solution
Fum Fail
Fumi tc
Hight temp
Depr Fail
No
acc
Raf
No
Pell
Atte
- The smokes motor is blocked
- The probe for speed control is broken
- No power supply to the motor
Replace the motor or verify if there is power supply
These operations must be performed by an
authorized technician
- The thermal couple is broken
- The thermal couple is disconnected
from the card
Check if the thermal couple is correctly connected
using the wiring diagram located in the tank or
proceed with the replacement of the component
These operations must be performed by an
authorized technician
- The tangential fan is broken
- Too much load of pellets
- No power supply to the tangential
motor
Verify if there is power supply
Replace the broken motor
Adjust the load of pellets
These operations must be performed by an
authorized technician
- The chimney is obstructed
- The chamber is dirty
- The sensor is defective
Check if the chimney and the chamber are clean
Check if the sensor is burnt and replace it
These operations must be performed by an
authorized technician
- No pellets in the tank
- It is the first ignition
Fill the stove with pellets
If it is the first ignition, see chapter 8
- Lack of current during the operation of
the stove
The equipment shall cool down and then
automatically shall perform the phase of ignition.
- Low temperature in the fire
chamber, the fire dies and the
pellet feeding stops.
Empty the burn pot and the restart the stove again.
Maybe you have to adjust the pellet feeding after the
running in of the gearmotor.
If the stove is new: Fill the
hopper with pellet. Set the stove on position 3 or 4 for
a min. period of 30 hours for a good settlement of the
motors and of the mechanical components. During
these 30 hours, set the room thermostat on
HOT.
- When it is started an ignition and the
stove has just gone OFF (normal
switching OFF or caused by an alarm)
When the stove goes in switching OFF (normal or
caused by an alarm) it is necessary to wait the
cooling of the machine and perform the cleaning of
the furnace. Only after performing these operations
you may proceed with a new ignition.
