Extraflame DIVINA Use And Maintenance Manual

8
TECHNICAL SPECIFICATIONS
All a.m. data are not binding, but valid just as an indication.
the right to make technical modifications for improving the product is reserved.
Height 858 mm. 884 mm.
Width 440 mm. 477 mm.
Depth 470 mm. 446 mm.
Weight 100 Kg. 110 Kg.
Fume exhaust pipe diameter 80 mm. 80 mm.
Max heating volume 100 m
3
100 m
3
Total power 1,7 - 5,1 kW/h 1,7 - 5,1 kW/h
Water power / kW/h / kW/h
Pellet consumption per hour 0,4 - 1,2 Kg/h 0,4 - 1,2 Kg/h
Absorbed electrical power 25 - 100 W 25 - 100 W
Lighting power +280 W +280 W
Power supply 230 V 50 Hz 230 V 50 Hz
Feed box capacity ~ 11 kg. ~ 11 kg.
Inlet/outlet water pipe “ / “ /
BabyFiamma
Preziosa
Preziosa
BabyFiamma
WALL DRILLING
SKETCH
AIR INTAKE PIPE
FUMES OUTLET PIPE
FUMES OUTLET PIPE ø 80
FUMES OUTLET PIPE ø 50

Extraflame DIVINA Specifications

General

Brand	Extraflame
Model	DIVINA
Category	Stove
Language	English
