Extraflame DIVINA Use And Maintenance Manual

9
TECHNICAL SPECIFICATIONS
All a.m. data are not binding, but valid just as an indication.
the right to make technical modifications for improving the product is reserved.
Height 1150 mm. 1041 mm. 1150 mm.
Width 610 mm. 520 mm. 610 mm.
Depth 576 mm. 513 mm. 576 mm.
Weight 170 Kg. 130 Kg. 170 Kg.
Fume exhaust pipe diameter 80 mm. 80 mm. 80 mm.
Max heating volume 220 m
3
150 m
3
220 m
3
Total power 2,5 - 11 kW/h 2,5 - 7,5 kW/h 2,5 - 11 kW/h
Water power / kW/h / kW/h / kW/h
Pellet consumption per hour 0,6 - 2,4 Kg/h 0,6 - 1,6 Kg/h 0,6 - 2,4 Kg/h
Absorbed electrical power 25 - 100 W 25 - 100 W 75 - 210 W
Lighting power +280 W +280 W +280 W
Power supply 230 V 50 Hz 230 V 50 Hz 230 V 50 Hz
Feed box capacity ~ 30 kg. ~ 25 kg. ~ 30 kg.
Inlet/outlet water pipe “ / “ / “ /
Divina
Bella Divina Plus
Divina
Bella
Divina Plus
A: FUMES OUTLET PIPE ø 80
B: AIR INTAKE PIPE ø 50
A
B
A
B
A
B
A: FUMES OUTLET PIPE ø 80
B: AIR INTAKE PIPE ø 50
A: FUMES OUTLET PIPE ø 80
B: AIR INTAKE PIPE ø 50
C: CANALISATION PIPE ø 80
