6. Carefully slide the power supply all the way into the power supply bay.
Figure 85: Installing an ExtremeSwitching 2000 W AC Power Supply
7. Push the power supply in until the latch snaps into place.
Caution
Do not slam the power supply into the switch.
8. Connect the power cord to the power supply and to a grounded AC power outlet.
Warning
Always be sure that the source outlet is properly grounded before plugging the AC power
cord into the AC power supply.
9. If the power supply is equipped with a power cord retainer, use the retainer to secure the power cord
to the power supply.
Replace a 2000 W AC Power Supply
Replacing AC Power Supplies
120 ExtremeSwitching 5520 Series Hardware Installation Guide

Extreme Networks ExtremeSwitching 5520 Series Specifications

General

Product Series	ExtremeSwitching 5520 Series
Category	Switch
Layer	Layer 3
Operating System	ExtremeXOS
Uplink Ports	4 x 10G SFP+
Management	Web, CLI, SNMP, REST API
Features	Advanced QoS
Form Factor	1U
Mounting	Rack-mountable
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% non-condensing
Dimensions (W x D x H)	440 x 420 x 44 mm
