Table 53: V300 Packaged Dimensions (continued)
V300-8P-2T-W Height: 3.08 in (7.82 cm)
Width: 10.85 in (27.56 cm)
Length: 11.52 in (29.26 cm)
V300HT-8P-2X
V300HT-8T-2X
Height: 3.07 in (7.79 cm)
Width: 10.15 in (25.78 cm)
Length: 14.46 in (36.72 cm)
Table 54: V300 Packaged Weight
V300-8P-2X
with 280W PSU
7.94 (3.6 kg)
V300-8T-2X
with 40W PSU
5.73 lb (2.6 kg)
V300-8P-2T-W 4.1 lb (1.86 kg)
V300HT-8P-2X
V300HT-8T-2X
3.97 (1.8kg)
Power Specifications
Note
When you use a redundant power supply (RPS), only redundant power – not additive power –
is supported. Thus, the PoE ports load does not increase when an RPS is added.
Table 55: V300 Power Options
V300-8P-2X DC Input: 54VDC, 4.5A max
V300-8T-2X DC Input: 12VDC, 1.5A max
V300-8P-2T-W The PoE PSE Budget is dynamically determined by the 802.3bt
Type 4 PD input power applied to its uplinks as follows:
2 x 90W = PoE ports load to 105W
1 x 90W = PoE ports load to 50W
2 x 60W = PoE ports load to 75W
1 x 60W = PoE ports load to 30W
2 x 30W = PoE ports load to 30W
1 x 30W = PoE ports load to 0W
V300HT-8P-2X DC Input: 54VDC, 4.5A max
V300HT-8T-2X DC Input: 12VDC, 1.5A max
Power Specifications Technical Specifications
136 ExtremeSwitching 5520 Series Hardware Installation Guide
