Table 50: Environmental Data (continued)
Packaged shock (half sine): 180 m/s
2
(18 G), 6 ms, 600 shocks
Packaged sine vibration: 5 to 62 Hz at velocity 5 mm/s,
62 to 500 Hz at 0.2 G
Packaged random vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct.
from 20 to 200 Hz
14 drops minimum on sides and corners at 42 inches (<15 kg box)
V300 Virtual Port Extender Specifications
The following V300 Virtual Port Extender models are available:
• V300-8P-2X
• V300-8T-2X
• V300-8P-2T-W
• V300HT-8P-2X
• V300HT-8T-2X
Table 51: V300 Unpackaged Dimensions
V300-8P-2X
V300-8T-2X
V300HT-8P-2X
V300HT-8T-2X
Height:1.73 in (4.4 cm)
Width: 7.76 in (19.71 cm)
Length: 212 in (538.48 cm)
V300-8P-2T-W Height: 1.73 in (4.4 cm)
Width: 8.26 in (21 cm)
Length: 7.48 in (19 cm)
Table 52: V300 Unpackaged Weight
V300-8P-2X
V300-8T-2X
V300HT-8P-2X
V300HT-8T-2X
3.31 lb (1.5 kg)
V300-8P-2T-W 3.22 lb (1.46 kg)
Table 53: V300 Packaged Dimensions
V300-8P-2X Height: 3.07 in (7.79 cm)
Width: 11.52 in (29.26 cm)
Length: 19.98 in (50.74 cm)
V300-8T-2X Height: 3.07 in (7.79 cm)
Width: 10.15 in (25.78 cm)
Length: 17.61 in (44.72 cm)
Technical Specifications V300 Virtual Port Extender Specifications
ExtremeSwitching 5520 Series Hardware Installation Guide 135
