Extron • Matrix 100 • User’s Manual 1-5
Matrix 100 I/O Module Specifications
Power . 90 - 260 VAC, 50/60 Hz, 60 Watts
Dimensions . 17" W, 15" D, 6.8" H
Shipping Weight . 22 lbs (10 kg)
Operating Temperature . 0° C - 50° C
Storage Temperature . -20°C - 70° C
MTBF . 35,000 Hours (demonstrated)
Approved . UL Listed
Warranty . 2 years parts and labor
MRAM Video (Medium Resolution Analog Module)
Connectors . BNC
Bandwidth . 175 MHz (-3 dB)
Crosstalk:
at 10 MHz . -50 dB(typical) See note 1.
at 100 MHz . -30 dB
Isolation:
at 10 MHz . -60 dB (typical) See note 2.
at 100 MHz . -55dB
Return Loss:
at 10 MHz . -20 dB
Input Impedance . 75 ohms
Output Impedance . 75 ohms
Switching Speed . 200 ns (nominal)
Input Signal . 0.3-1.0 V p-p (max dc offset ± 0.30 V)
Gain . Unity ±1%
Composite Video Module
Frequency Response . -0.5 dB @ 5 MHz; -3.0 dB @ 15 MHz
Differential Gain . 0.5%
Differential Phase . 1.3°
Line and Field Tilt . Less than 0.1%
Isolation between outputs Greater than 40 dB @ 5 MHz
Crosstalk . Greater than 40 dB @ 5 MHz
CMRR . -60 dB
Propagation Delay . 10ns
Input Signal . 75 ohms, analog, 0-1.0 V p-p
. (max dc offset ±0.30 V)
Gain . Unity
Sync Module
Input Impedance . 510 ohms
Output Impedance . 75 ohms
Max. Input Voltage . ±5 V
Input Sensitivity . 500 mV p-p
Output Level . 4.5 V p-p not terminated;
. 2.2 V p-p terminated at 75 ohms
Max. Propagation Delay . 64ns H to L (41 ns L to H)
Max. Rise/Fall Time . 8 ns H to L (3.6 ns H to L)
Polarity . Follows input
Note 1: Crosstalk is the
attenuation of all hostile
signals relative to a given
input-output connection.
Note 2: Isolation is the
attenuation of an input signal
relative to an un-selected
output when all inputs have
the same signal applied
simultaneously.
Chapter 1 • Introduction to Matrix 100
