IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 29
X@
= Input video format 1 = RGB
2 = YUV
3 = S-video
4 = composite
5 = HDMI/DVI
X#
= Horizontal or vertical start 0-255 (128 = default)
X$
= Pixel phase 0-63 (31 = default)
X%
= Total lines ±512 of the default value
X^
= Total pixels ±512 of the default value
X&
= Active pixels ±512 of the default value
X*
= Active lines ±256 of the default value
X(
= Enable or disable 0 = off or disabled
1 = on or enabled
X1)
= Input standard 0 = no signal detected on the current input
1 = NTSC 3.85
2 = PAL
3 = NTSC 4.43
4 = SECAM
- = N/A (occurs when the input is active RGB,
YUV, or HDMI signal)
X1!
= Internal temperature In degrees Celsius
X1@
= Horizontal and vertical
frequencies
xxx.x
X1#
= Text label Up to 16 characters
X1$
= Picture adjustment 0-127 (64 = default)
X1%
= Horizontal position
±2048
X1^
= Vertical position
±1200
X1&
= Horizontal size
0-04096
X1*
= Vertical size
0-02400
X1(
= Test patterns 0 = off (default)
1 = crop
2 = alternating pixels
3 = crosshatch
4 = color bars
5 = grayscale
6 = blue mode
7 = audio test (pink noise)
X2)
= User presets
1-16
X2!
= Input presets
1-16
X2@
= Screen saver timeout 0 = OSD is never displayed, output sync is
instantly disabled with no active input
1-500 = 1 second increments
501 = OSD bug never times out, output sync
never times out (default)
