IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 30
X2#
= Executive mode status 0 = off or disabled (default)
1 = mode 1 (complete front panel lockout)
2 = mode 2 (only allow input switching and
Auto-Image)
X2$
= Verbose mode 0 = clear or none
1 = verbose mode
2 = tagged responses
3 = verbose mode and tagged responses
X2%
= Device name Text label up to 24 characters drawn from the
alphabet (A-Z), digits (0-9), and the minus or
hyphen symbol (-).
X2^
= Overscan 0 = 0.0% (default for RGB, HDMI)
1 = 2.5% (default for RGBcvS, YUV, S-video,
and CV)
2 = 5.0%
X2&
= Aspect ratio setting 1 = fill (default)
2 = follow
X2*
= Screen saver mode 1 = black output (default)
2 = blue output with OSD text
X2(
= Video output mute 0 = unmute
1 = mute video
2 = mute video and sync
X3)
= Auto-Image threshold value 0-100 (where 0 = black and 100 = white;
025 = default)
X3!
= HDCP status 0 = no sink or source device detected
1 = sink or source detected with HDCP
2 = sink or source detected but no HDCP
X3@
= Video switching effect 0 = cut
1 = fade through black (default)
X3#
= HDCP mode 0 = HDMI outputs are always authenticated,
but only encrypted when required
1 = HDMI outputs are always authenticated and
encrypted
2 = HDMI outputs are always authenticated,
with continuous DVI trials, but only
encrypted when required
3 = HDMI outputs are always authenticated and
encrypted, with continuous DVI trials
X3$
= TMDS output format 0 = auto (based on the display EDID: default)
1 = DVI RGB 444
2 = HDMI RGB “Full”
3 = HDMI RGB “Limited”
4 = HDMI YUV 444 “Full”
5 = HDMI YUV 444 “Limited”
6 = HDMI YUV 422 “Full”
7 = HDMI YUV 422 “Limited”
X3%
= Auto switch mode 0 = disable
1 = prioritizes the highest numbered active input
2 = prioritizes the lowest numbered active input
X3^
= Audio volume -100 to 0 in 1 dB steps (where -100 = -100 DB
and 0 = 0 dB; -10 = default)
