Network Button Panels • Hardware Features and Installation 20
3. Attach the wallplate to the NBP
• For decorator-style models: Insert the included screws through the circular
holes in the wallplate and the tabs on the NBP (see figure 17 and figure 18 on
page18). Hand tighten the screws using a flat bladed screwdriver until snug.
• For US gang models (NBP100 and NBP200): Align the faceplate openings
with the buttons, knob, and LEDs, and place the faceplate against the unit (see
figure 19 and figure 20 on the previous page. The magnetic catches fasten the
faceplate onto the front of the unit.
