ShareLink Pro 500 • SIS Configuration and Control 34
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Output Audio Mute
Mute audio output
1*1Z/z
Amt1*1]
Mute audio outputs (mutes both HDMI
and Analog audio)
Unmute audio output
1*0Z/z
Amt1*0]
Unmute audio outputs (unmutes both
HDMI & Analog audio)
View audio output mute
1Z/z
X1(]
Amt1*X1(]
View current audio mute status
(Verbose mode 2/3)
Input aspect ratio (per input)
Set to Fill
EX2!*1ASPR} AsprX2!*1]
Set input aspect ratio to Fill
Set to Follow
EX2!*2ASPR} AsprX2!*2]
Set input aspect ratio to Follow
View aspect ratio setting
EX2!ASPR} X2@]
AsprX2!*X2@]
View input aspect ratio setting
(Verbose mode 2/3)
Analog Audio Output Volume
Specify volume
X2#V/v VolX2#]
Set volume level. Response is 3 digits.
Ex: Vol-050
Increment volume
+V
VolX2#] Volume level is X2#
Decrement volume
-V
VolX2#] Volume level is X2#
View volume
V
X2#]
View volume level
KEY:
X1( = Mute status
0 = Unmute (default) 1 = mute
X2! = Input type
1 = HDMI
X2@ = Input aspect ratio setting
1 = Fill 2 = Follow (default)
X2# = Volume adjustment range
-100 to 0 = (default is -30 dB)
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Front Panel Lockout
Front panel executive
mode
X2*X ExeX2*]
Lock/unlock front panel
View lockout status
X/x
X2*]
ExeX2*]
(Verbose mode 2/3)
KEY:
X2* = Executive mode
0 = Off (default)
1 = On
