Room Scheduling System • Room Agent Installation and Configuration 17
3. Enter the IP address of the desired panel in the IP Address/Hostname: field
(see figure 12,
1
on the previous page).
4. If the panel is password protected, enter the password in the Password: field
(
2
).
NOTE: All panels ship with the default, case-sensitive, password “extron”.
5. Click the Add button (
3
). Room Agent searches for the requested panel and, if found,
adds it to the Manually Added Panels pane (see figure 13).
NOTES:
•
TLS scheduling panels
ship with scheduling firmware installed. All except the
TLS 525M, TLS 725M, or TLS 1025M require firmware version 2.01.0010-b001
or higher to connect to them. TLS 525M, TLS 725M, or TLS 1025M requires
version 1.00.0004-b001.
•
TLP Pr
o touchpanels ship with control firmware installed. Room Agent
requires that scheduling panels run different, scheduling, firmware, version
2.01.0010-b001 or higher to connect to them.
•
For either family of
panel models, if you receive the message
Cannot
connect to this device, click OK in the message dialog box, STOP HERE
and update the panel firmware (see Update Firmware on page 46, beginning
at step 5).
Figure 13. Panel Management View with Panels Assigned
