Room Scheduling System • Reference Information 64
Panel Installation Overview
The Extron panel models have the following mounting capabilities:
• TLS 520M and TLP Pro 520M Panels —
• Mountable in a wall
• Mountable on a non-porous surface, such as a conference room window with the
optional Extron SMB 1 Low Profile Surface Mount Box and GMK 1 Glass Mount Kit
• TLS 525M Scheduling Panel —
• Mountable in a wall with an optional RWM 1 Recessed Wall Mount Kit
• Mountable on a non-porous surface, such as a conference room window with the
optional Extron SMK 1 Surface Mount Kit
• TLS 725M Scheduling Panel —
• Mountable in a wall with the optional RWM 2 Recessed Wall Mount Kit.
• Mounted on a non-porous surface, such as a conference room window with the
optional Extron SMK 2 Low Profile Surface Mount Kit
• TLS 1022M AND TLP Pro 720M Panels — Mountable in a wall
• TLS 1022T AND TLP Pro 720T Panels — Mountable to a two-gang, UL-certified
junction box; a two-gang mud ring; or directly into or onto any solid surface, such as
brick, wood, masonry, or drywall (with an optional Extron LPVM-1 Low Profile VESA
Mount)
• TLS 1025M Scheduling Panel —
• Mountable in a wall with the optional RWM 2 Recessed Wall Mount Kit.
• Mounted on a non-porous surface, such as a conference room window with the
optional Extron SMK 3 Low Profile Surface Mount Kit
All panels can receive power and communication over a single Ethernet cable. Power over
Ethernet (PoE) eliminates the need for a local power supply. PoE requires a PoE injector,
which is sold separately.
ATTENTION:
•
The following guidelines ar
e overviews only. For complete panel installation
instructions and safety guidelines, visit www.extron.com and see the applicable
panel user guides.
•
Les consignes suivantes n’of
frent qu’une description succincte. Pour accéder aux
consignes complètes d’installation et de sécurité des écrans tactiles, consultez les
manuels d’installation pertinents sur www.extron.com.
