Extron electronics XTP II CrossPoint 6400 User Manual

SIS Command and Response Table for Advanced Matrix Switcher Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Information requests (continued)
Request system status
S
See below
XTP II CrossPoint 6400:
X5@
•
X5@
•
X5#
•
X5#
•
X5#
•
X5#
•
X5$
•
X5$
•N/A•N/A•N/A•N/A•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
N/A•N/A•N/A•N/A•
X5%
•
X5%
•
X5%
•
X5%]
XTP II CrossPoint 3200:
X5@
•
X5@
•
X5@
•
X5@
•
X5@
•
X5#
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5$
•
X5%
•
X5%
•
X5%
•
X5%]
XTP II CrossPoint 1600 (no redundant power supply):
X5@
•
X5@
•
X5@
•
X5#
•
X5$
•
X5$
•
X5%
•
X5%]
XTP II CrossPoint 1600 (redundant power supply):
X5@
•
X5@
•
X5@
•
X5@
•
X5@
•
X5#
•
X5$
•
X5$
•
X5%
•
X5%
•
X5%
•
X5%]
Response description (XTP II CrossPoint 6400):
12 V
•3 V•PS1 °F•PS2 °F•PS3 °F•PS4 °F•PS1 RPM (fan)•PS2 RPM•Meaningless data (N/A)•(N/A)•(N/A)•(N/A)•
PS3 RPM•PS4 RPM•Fan 1 RPM (F1)•F2•F3•F4•F5•F6•(N/A)•(N/A)•(N/A)•(N/A)•PS status 1 (PS1)•PS2•PS3•PS4
]
Response description (XTP II CrossPoint 3200):
PS1 (12 V)
•PS2 (12 V)•PS3 (12 V)•PS4 (48 V)•3.3 V•°F•Fan 1 RPM (F1)•F2•F3•F4•F5•F6•F7•PS status 1 (PS1)•PS2•PS3•PS4
]
Response description (XTP II CrossPoint 1600, without optional redundant power supply):
PS1 (12 V)
•PS2 (48 V)•3.3 V•temp. (°F)•Fan 1 speed (F1)•F2•PS status 1 (PS1)•PS2
]
Response description (XTP II CrossPoint 1600, with optional redundant power supply):
PS1 (12 V)
•PS2 (48 V)•PS3 (12 V)•PS4 (48 V)•3.3 V•°F•Fan 1 speed (F1)•F2•PS status 1 (PS1)•PS2•PS3•PS4
]
NOTE: If a primary power supply that is not backed up by a redundant supply fails, return the switcher to Extron for immediate repairs.
If a backed up power supply, a redundant power supply, or a cooling fan fails, return the switcher at your earliest opportunity.
Example
(XTP II CrossPoint 3200):
S
See below
Fan 2 rotating at 888 RPM12V power supply 1 at 12.01V
Temperature is 73.4 °F
All 4 power supplies installed
12.01
•11.31•11.31•48.00•+3.30•+73.40•00892•00888•00892•01061•01022•00892•00888•1111
View all input connections
0LS
X%
1
X%
2
X%
3
...
X%
n
]
16, 32, or 64 (
n
)
X%
s; each is the connection
status of an input, starting from input 1.
Example
(XTP II CrossPoint 3200):
0LS
Input:
Response Status:
No input detected
Sync detected Sync detected
1 2345
6
7 8 9
1011
12
13
32
0 0 0 1 1 1 0 1 0 0 1 0 1. . .0
NOTE: X% = Input signal status 0 = No signal detected 1 = Signal detected
X5@ = Voltage Positive or negative voltage and magnitude
X5# = Internal temperature Degrees Fahrenheit
X5$ = Fan speed RPM
X5% = Power supply installation status 0 = No power supply installed 1 = Power supply installed
Symbol definitions for IP- and Remote port specific SIS commands
X6!
= Matrix name (Up to 24 alphanumeric characters)
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page 118).
X6@
= Default name XTP-II-CP-nn00 + last 3 pairs of MAC address. nn = 16, 32, or 64.
X6#
= Time and date (for set) In the format: MM/DD/YY•HH:MM:SS where:
MM = month: 01 (January) through 12 (December)
DD = 01 through 31
YY = 00 through 99
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X6$
= Time and date (for read) In the format: Day,•DD•Mmm•YYYY•HH:MM:SS where:
Day of the week: Mon through Sun
DD = 01 through 31
Mmm = month: Jan through Dec
YYYY = 2000 through 2099
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 115
