Configuration Worksheets
Rather than trying to remember the configuration for each preset, use worksheets to record
this information. Make copies of the blank worksheet on page 73 (XTP II CrossPoint 6400),
page 74 (XTP II CrossPoint 3200), or page 75 (XTP II CrossPoint 1600) and use one for
each preset configuration. Cross out all unused or inactive inputs and outputs. Use different
colors for video and audio.
NOTE: All of the equipment in the following examples is connected through the
appropriate input board, output board, transmitter, or receiver.
Worksheet Example 1: System Equipment
Figure 53 shows a portion of a worksheet for an XTP II CrossPoint 1600 in a fictional
organization with the system hardware annotated. Inputs 10, 11, and 13 have no
connection in this organization, so they are crossed out on the worksheet. Similarly,
outputs 7 and 9 through 16 are crossed out.
1 2345678
12345678
91011
11
12 13
10
9
Input sources
Output destinations
Preset # Title: Video: Audio:
Fill in the preset number and use colors, dashes, etc., to make connecting lines.
Indicate if the configuration is for video, audio, or both.
Classroom
#1 VCR
USP 405
Audio
CD
PC 2
RGB 202
PC 1
RGB 202
Weekly status mtg 3
Camera
#2
Camera/
mic - Main
podium
Main hall
FP #1
Main hall
FP #2
Podium
monitor
Sound
system
#1
Sound
system
#2
VCR
(VSC 500)
DA 6
Classroom
#2 VCR
USP 405
Laptop
RGB 202
Rack DVD
(USP 405)
VTG 400
Figure 53. Worksheet Example 1: System Equipment
Inputs include PCs, an audio CD player, cameras, and an Extron VTG 400DVI. Output
devices include monitors, projectors, a stereo, a VCR for recording presentations, and a DA.
The VTG 400DVI video test generator connected to input 12 enables a video test pattern to
be sent to one, several, or all output devices for problem isolation or adjustment purposes.
An audio test tape or CD could be used in a similar manner to check out the audio
components.
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Operation 70
