Extron electronics XTP II CrossPoint 6400 User Manual

SIS Command and Response Table for Advanced Matrix Switcher Commands
The table that starts below shows commands for advanced operation of the
XTP II CrossPoint matrix switcher frame. Commands shown affect the entire switcher,
regardless of the input boards and output boards installed or any connected endpoints.
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Black video resolution within the matrix switcher for audio-breakaway ties
Set black signal resolution for the
matrix switcher inputs
E
A
X1)
*
X1!
AFMT
}
AfmtA
X1)
*
X1!]
Set the black video signal resolution for
the matrix switcher.
Example
(XTP II CrossPoint 3200):
E
A33*2AFMT
}
AfmtA33*02
]
Output a black video signal at 1280x720p
@ 50 Hz when audio is broken away.
View black signal resolution for the
matrix switcher inputs
E
A
X1)
AFMT
} X1!]
Video and audio test patterns
NOTES:
• The test pattern (J) commands send test patterns to all outputs for setup and calibration. This is separate from the black video signal
insertion into audio breakaway ties (
E
B AFMT command on page 102 and the
E
E AFMT commands on page 96 and
page 98).
• The available audio test pattern is a 1-kHz audio tone.
Output test pattern on all outputs
X4#
J Tst
X4#]
Output the selected test pattern.
Disable test pattern
0J
Tst00
]
Normal operation, test pattern disabled.
View test pattern status
J
X4#]
Names
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page 118).
Write global preset name
EX#
,
X4$
NG
}
Nmg
X#
,
X4$]
Example:
E
1,Security 1NG
}
Nmg01,Security 1
]
Name global preset 1 “Security 1.”
Read global preset name
EX#
NG
} X4$]
Example:
E
2NG
}
Security 2
]
Write input name
EX^
,
X4$
NI
}
Nmi
X^
,
X4$]
Example:
E
1,Podium camNI
}
Nmi01,Podium cam
]
Name input 1 “Podium cam.”
Read input name
EX^
NI
} X4$]
Write output name
EX@
,
X4$
NO
}
Nmo
X@
,
X4$]
Example:
E
1,Main PJ1NO
}
Nmo01,Main PJ1
]
Name output 1 “Main PJ1.”
Read output name
EX@
NO
} X4$]
Front panel locks
NOTE: See Setting the Front Panel Locks (Executive Modes) on page 64 for more information on the Lock modes.
Lock all front panel functions
1X
Exe1
]
Enable Lock mode 1.
Lock advanced front panel functions
2X
Exe2
]
Enable Lock mode 2.
Unlock all front panel functions
0X
Exe0
]
Enable Lock mode 0.
View lock status
X
X4%]
NOTE: X@ = Output number
X# = Global preset number
X^ = Input number (for other than tie)
X1) = Switcher model
X1! = Resolution, rate for black screen
01 – 16, 32, or 64
01 – 32
01
– 16, 32, or 64
17 (XTP II CrossPoint 1600), 33 (XTP II CrossPoint 3200), or 65 (XTP II CrossPoint 6400)
2 = 1280x720p @ 50 Hz 4 = 1280x720p @ 60 Hz 6 = 1920x1080p @ 60 Hz
X4# = Test pattern and resolution
00
= Disable (
default
)
Color bars
No audio
Color bars
Audio
Black screen
No audio
Black screen
Audio
720p, 50 Hz
01 07 02 08
720p, 60 Hz
03 09 04 10
1080p. 60 Hz
05 11 06 12
X4$ = Name
X4% = Front panel lock
Up to 12 alphanumeric characters
0
= Lock mode 0 (unlocked) 1 = Lock mode 1 2 = Lock mode 2 (default)
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 110
