Maintenance and

Modiﬁcations

This section covers maintaining and modifying the XTP II CrossPoint matrix switchers, including:

• Mounting the Switcher

• Battery and Power Precautions

• Removing and Installing an Input or Output Board or Blank Panel

• Removing and Installing a Power Supply Assembly (XTP II CrossPoint 6400)

• Replacing and Terminating the Power Cable (XTP II CrossPoint 6400)

• Removing and Installing Button Labels

ATTENTION:

• Installation and service must be performed by authorized personnel only.

• L’installation et l’entretien doivent être effectués par le personnel autorisé

uniquement.

Mounting the Switcher

The XTP II CrossPoint 6400 is housed in a rack-mountable, 20U high metal enclosure. The

XTP II CrossPoint 3200 is housed in a 10U enclosure. The XTP II CrossPoint 1600 is in an

5U high enclosure. All models have built-in mounting flanges for standard 19-inch wide racks.

UL Guidelines

The following Underwriters Laboratories (UL) guidelines pertain to the installation of the

matrix switcher into a rack.

• Elevated operating ambient temperature — If installed in a closed or multi-unit rack

assembly, the operating ambient temperature of the rack environment may be greater

than room ambient. Therefore, consider installing the equipment in an environment

compatible with the maximum ambient temperature specified by Extron (Tma = +32 to

+122 °F [0 to +50 °C]).

• Reduced air flow — Installation of the equipment in a rack should be such that the

amount of air flow required for safe operation of the equipment is not compromised.

• Mechanical loading — Mounting of the equipment in the rack should be such that a

hazardous condition is not achieved due to uneven mechanical loading.

• Circuit overloading — Consideration should be given to the connection of the

equipment to the supply circuit and the effect that overloading of the circuits might have

on overcurrent protection and supply wiring. Appropriate consideration of equipment

nameplate ratings should be used when addressing this concern.

• Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment

should be maintained. Particular attention should be given to supply connections other

than direct connections to the branch circuit (such as the use of power strips).

XTP II CrossPoint 1600, 3200, and 6400 Switchers • Maintenance and Modifications 143
