FX15 Controller Technical Bulletin
Address Selection
Use the DIP switches (see Figure 13) to select the serial address of the
FX15 controller in the N2 Open network. The address selection occurs
in binary mode.
Examples:
• 1
st
ON, all others open
address = 2
0
+ 0
1
+ … = 1
• 1
st
ON, 4
th
ON, all others open
address = 2
0
+ 0
1
+ 0
2
+ 2
3
= 9
The address zero is not allowed. The factory default address
configuration is 1.
IMPORTANT: Cycle the controller power to activate the new serial address.
Network Layout
Refer to the N2 Communication Bus Technical Bulletin (LIT-636018).
