FX16 Master Controller Technical Bulletin
26
LP-KIT007-001C is a 1.5 m (4.9 ft) long cable with DB9 male
connector for the connection to a standard Land Line modem. See
Figure 20.
11
22
33
44
55
66
77
88
99
10
FX16-011_10 2003
Modem-CD
RX-Data
TX-Data
GND "D"
Modem-DSR
Modem-RTS
Modem-CTS
Modem-RI
Modem-DTR
White
Yellow
Grey
Red
Black
Green
Blue
Brown
Purple
1
6
9
5
Standard Modem side
FX16 side
DB9 male connector
9
5
1
10
2
Connector AMP 5x2
12
AMP crimp
Figure 20: Connection Details of Standard Modem Cable
LP-KIT007-002C is a 1.5 m (4.9 ft) long cable with a DB15 male
connector for the connection to the GSM modem. See Figure 21.
11
62
23
84
95
76
12 7
11 8
13
14
9
10
FX16-012_10 2003
Modem-CD
RX-Data
TX-Data
Reset
GND "D"
Modem-DSR
Modem-RTS
Modem-CTS
Modem-RI
Modem-DTR
White
Yellow
Grey
Red
Black
Green
Blue
Brown
Purple
Pink
GSM Modem side
FX16 side
9
5
1
10
2
AMP 5x2 AMPMODU II
12
AMP crimp
HD DB15 Male
DB15 male connector
Note: The number 1 in the AMP connector is
in corrispondence to the AMP printing.
Figure 21: Connection Details of GSM Modem Cable
