FX16 Master Controller Technical Bulletin
58
AO V ~ Com
24V
AO Com
75
AO Com
787776
AO3 AO4
8079
AO V ~ Hot
71
AO Com AO Com
747372
AO1
AO2
FX16
91
Earth
V ~ Hot
9392
V ~ Com
120/230VAC
24 VAC
2
A
Figure 51: Connecting an Analog Output - FX16D and FX16X (Not Rev. A)
Controllers
Table 18: Analog Output Powered by 24 VAC
FX16 Terminals Description
AO Com (77)
Common Reference
AO4 (78)
Analog Output 0-10 V
AO V~ Com (79)
Common Reference
AO V~ Hot (80)
Power Supply 24 VAC
Note: The numbers between the brackets are the FX16 terminal
numbers.
IMPORTANT: Not respecting the power supply polarity results in a short
circuit causing the blowing of the external fuse.
To achieve isolation from the microprocessor circuits and better
immunity against electrical disturbances, use a separate 24 VAC power
supply to power the analog outputs (terminals 79, 80). See
Figure 52.
15 V
A
