FX16 Master Controller Technical Bulletin 59
AO V ~ Com
24V
AO Com
75
AO Com
787776
AO3 AO4
8079
AO V ~ Hot
71
AO Com AO Com
747372
AO1
AO2
FX16
91
Earth
V ~ Hot
9392
V ~ Com
220Vac24 Vac
220Vac24 Vac
Figure 52: Separately Powering Analog Outputs
- FX16D and FX16X (Not Rev. A) Controllers
FX16X Rev. A Master Controller
The four analog outputs of the FX16 Master Controller (Rev. A) are
powered internally by the 24 VAC voltage power supply of the
controller. The power supply of the FX16 Master Controller (Rev. A) is
isolated from the Central Processing Unit (CPU) circuits, so that the
isolation of the analog outputs is maintained. Terminal 80 is not
connected internally but can be used to connect power to the actuator.
AO Com
AO Com
75
AO Com
787776
AO3 AO4
8079
no connection
71
AO Com AO Com
747372
AO1
AO2
FX16
91
Earth
V ~ Hot
9392
V ~ Com
120/230VAC
24 VAC
2
A
Figure 53: Connecting an Analog Output - FX16X Rev. A Controller
15 V
A
3 V
A
15 VA
