Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOR-E-48I32O / RIOR-E-48I32O-ANALOG (ETHERCAT).
Connections.
ꞏ116ꞏ
REF. 2107
Cable characteristics.
Fagor Automation supplies the required cables for EtherCAT communication; when using
third-party cables, these must be of the same category as those supplied by Fagor (see
tables). There are different types of cables depending on length and dynamic and static
installation characteristics. EtherCAT cables should never be installed next to power cables
and they should never cross over each other at a 90 degree angle.
Element connection.
In order to ensure proper performance, the connection cable must be inserted all the way
into the connectors so they're latched. This ensures that the cable is properly latched and
does not come off due to vibration.
ECAT-CABLE cable
Type. Industrial Cat 6A shielded 8-wire Ethernet cable (twisted pairs).
Diameter. 6.3 mm - 6.9 mm.
Flexibility. Minimum static bending radius 4 x diameter.
Minimum dynamic bending radius 8 x diameter.
Covering. PVC. Polyvinyl chloride.
Temperature. Work: -20 ºC / 80 ºC (-4 ºF / 176 ºF).
Storage: -20 ºC / 80 ºC (-4 ºF / 176 ºF).
Color. Yellow, RAL 1021.
Maximum length. 7 m (23 ft).
ECAT-CABLE-FLEX cable
Type. Industrial Cat 6A shielded 8-wire Ethernet cable (twisted pairs).
Diameter. 6.3 mm - 6.9 mm.
Flexibility. Minimum static bending radius 4 x diameter.
Minimum dynamic bending radius 8 x diameter.
Covering. PUR. Polyurethane.
Temperature. Work: -40 ºC / 80 ºC (-40 ºF / 176 ºF).
Storage: -40 ºC / 80 ºC (-40 ºF / 176 ºF).
Color. Yellow, RAL 1021.
Maximum length. 100 m (328 ft).
