Fagor CNC 8065elite T User Manual

Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIO5 REMOTE MODULES. (CANOPEN PROTOCOL).
3.
Power supply.
ꞏ33ꞏ
REF. 2107
GND
L
SH
SH
H
X3
GND
L
SH
SH
H
X2
CAN
POWER
ANALOG I/O
ERR
RUN
X1
CHS
GND
+24V
4
0
1
F
E
D
C
B
A
9
8
7
6
5
3
2
ADDRESS
SPEED
1
0
LT
1
0
X4
O1+
O1-
SH
X5
RL1
R1+
R1-
RF1
SH
X6
+12
I1+
I1-
SH
-12
GND
Connector ꞏX1ꞏ.
Power supply.
Power supply with analog inputs and
outputs.
CAN bus. ꞏSPEEDꞏ selector.
CAN bus transmission speed.
CAN bus. ꞏADDRESSꞏ selector.
Address (node) of the element within the CAN
bus.
CAN bus. Leds.
Status indicators.
CAN bus. ꞏSTꞏ selector.
Line terminating resistor.
CAN bus. Connector ꞏX2ꞏ.
CAN bus connection.
CAN bus. ꞏX3ꞏ connector.
CAN bus connection.
Connector ꞏX4ꞏ.
4 general purpose analog
outputs.
Connector ꞏX5ꞏ.
2 PT100 inputs.
Connector ꞏX6ꞏ.
4 differential analog inputs.
