Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
4.
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
RIOW-CANOPEN-STAND module. Leading (first) module.
ꞏ60ꞏ
REF. 2107
Power supply status indicator LED's
Led Color Function
A Green The LED turns on when the module is under
power.
B Green The LED turns on if the side jumpers have 24 V.
C
A
D
B
