June 2014 PLT-01277, Version: 1.2
Page 4-3 Printer Preferences
4.1.1 Card Size
Select the appropriate card option (CR-80 or CR-79):
CR-80: This selection is the default size for the card printer with a print area 3.375 in x 2.125 in x
30 mil (53.6 mm x 85.5 mm x 30 mil).
CR-79: Use this selection to print to cards with a print area 2.110 in x 3.366 in x 30 mil (53.6mm x
85.5 mm x 30 mil).
Note: These print area dimensions are 1mm (.04") larger than the actual card size. This extension
enables the printer to overprint images so they appear edge-to-edge when transferred to the card.
For this reason, when designing a card format, always set the card size or page size within the card
design program to the exact print length and width dimensions listed in the printer driver
4.1.2 Card Thickness
Select the card thickness (mil) value from the drop-down list. Options are 10, 20, 30, and 40 mil.
Default is 30 mil.
4.1.3 Orientation
Select either the Portrait or Landscape option.
Portrait: The card will print in a vertical orientation.
Landscape: The card will print in a horizontal orientation.
4.1.4 Copies
Set the number of copies to be printed. Range is 1 to 10000.
