Fargo C50 Configuration Guide

June 2014 PLT-01277, Version: 1.2
Page 5-7 ToolBox
5.4.1 Settings and Troubleshooting
Setting Description Troubleshooting
Head Resistance
Printhead resistance is set
to an incorrect value.
Locate the actual resistance value on the
printhead, for example, R=XXX.
Print Left of Form
Adjusts the vertical
position of the printed
image on the card; so it
appears centered.
Reserved
Image Darkness
Adjusts the overall
darkness of the printed
image by increasing or
decreasing the amount of
heat used by the
printhead when printing.
Lighten the printed image by clicking or enter
the exact negative value decreasing the
printhead heat.
Darken the image by clicking or entering a
positive value increasing the amount of
printhead heat.
IMPORTANT: If this setting is set too high, the
ribbon may jam or break.
Print Top of Form
Adjusts the length-wise or
horizontal position of the
printed image on the card
(so it appears to be
centered)
Reserved

Fargo C50 Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Resolution	300 dpi
Connectivity	USB 2.0
Print Speed	24 seconds per card (YMCKO)
Card Capacity	30 card output hopper
Card Size	CR-80 (3.375" x 2.125")
Dimensions	13.7" W
Weight	7.5 lbs (3.4 kg)
Operating System Compatibility	Windows 7, 8, 10
