DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 22
.
Step
Procedure
5
NOTE: In some cases you may need to remove the Display.
Unsnap the display by pivoting from the top DOWN to release the bottom tabs.
Remove the ribbon cable from the mainboard.
6
Remove the screw (F000178) holding the card Input Hopper to the frame.
