DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 23
.
Step
Procedure
7
Remove 2 screws (F000178) from the bottom of the Printer.
Release the cable connection.
8
Remove the Input Hopper by tilting back and away from the frame. There are tabs at the bottom that
hold the hopper to the frame.
9
Remove the screw that holds the Output Cover in place.
