DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 91
.
Step
Procedure
3
Remove the Retaining Ring (140048) and Platen Drive Gear ( 810265)
4
Remove the 3 screws (F000182) that hold the assembly to the frame.
Upper Module
Lower Module
