MCDWIN Program
ComTec GmbH 5-3
Open All
By selecting the Open All menu item, all available Displays are shown. The windows of the last
opened Display becomes active.
Close All
By selecting the Close All menu item, all available Displays are closed.
Compare...
The Compare... menu item allows to compare single spectra.
To use this feature it is necessary to have at least two webMCA devices defined in the
WEBMCA.INI file also if only one webMCA is physically available. The software can run for
the second webMCA in demo mode.
A Display window containing a single spectrum must be active; clicking this menu item opens then
a dialog box to select one or more of available other single spectra Displays. The selected spectra
are then plotted into the active Display window in a different color.
Print...
The Print menu item prints a Display to the printer. Only the visible part of the spectra will be
printed. The size and position of the graphic on paper can be adjusted in a dialog box.
Figure 5.3: File New Display dialog box
Figure 5.4: Compare dialog box
