Fastjet A470 Series - Printhead Component Details

2.5.Printhead
2.6. Ink Core
Ink Core（Left View） Ink Core（Right View）
Deflection Plate
Nozzle
Charge Electrode
Gutter Pipe
Phase Detector
Last Chance Filter
Nozzle connector
Page 6
* Exhaust Air Switch
Condenser
Cover
Suction pipe
Drain Pipe
* Exhaust Vent Plug
*
Please remove the exhaust vent plug and turn on
exhaust air switch before use.
Gear Pump
