Chapter 6 Description of Operations
PAGE 6-48
D-No.304 Communication Speed Setting range: 0 ~ 4 (CC-Link, DeviceNet)
The communication speed of the fieldbus set in the controller is indicated.
Fieldbus Type
System Parameter D-No.304
0
1
2
3
4
CC-Link
156kbps
625kbps
2.5Mbps
5Mbps
10Mbps
DeviceNet
125kbps
250kbps
500kbps
-
-
D-No.305 Occupied Stations Setting range: 1 ~ 4 (CC-Link)
The number of occupied stations of the fieldbus set in the controller is indicated.
D-No.306 Extended Cyclic Setting Setting range: 1, 2, 4, 8 (CC-Link)
The extended cyclic setting of the fieldbus set in the controller is indicated.
D-No.307 I/O Setting Byte Length “PLC ￫ Master Axis” [byte]
(besides standard IO and expansion IO)
The I/O setting byte length for “PLC ￫ MASTER Axis” of the fieldbus set in the controller is indicated.
D-No.308 I/O Setting Byte Length “Master Axis ￫ PLC” [byte]
(besides standard IO and expansion IO)
The I/O setting byte length for “MASTER Axis ￫ PLC” of the fieldbus set in the controller is indicated.
D-No.309 Message Block Byte Length [byte] (besides standard IO and expansion IO)
The message block byte length of the fieldbus set in the controller is indicated.
Fieldbus type
CC-Link
DeviceNet
PROFIBUSDP-V1
PROFINET IO
EtherNet/IP
144byte
250 byte
64 byte
250 byte
250 byte
D-No.310 Message Setting Byte Length “PLC ￫ Master Axis” [byte]
(besides standard IO and expansion IO)
The message setting byte length for “PLC ￫ MASTER Axis” of the fieldbus set in the controller is
indicated.
D-No.311 Message Setting Byte Length “Master Axis ￫ PLC” [byte]
(besides standard IO and expansion IO)
The message setting byte length for “MASTER Axis ￫ PLC” of the fieldbus set in the controller is
indicated.
