Chapter 6 Description of Operations
PAGE 6-47
D-No.300 Connected Fieldbus Information
The type of fieldbus installed on the Expansion controller 1 is indicated.
D-No.301 ANYBUS-CC Version (besides standard IO and expansion IO)
The ANYBUS-CC version of the Expansion controller 1 is indicated.
D-No.302 controller Setting Fieldbus Information
The type of fieldbus set in the controller is indicated.
D-No.303 Station No. (Node Address) (CC-Link, DeviceNet, PROFIBUSDP-V1)
The station No. (node address) of the fieldbus set in the controller is indicated.
Fieldbus Type
CC-Link
DeviceNet
PROFIBUSDP-V1
1～64
0～63
0～125
Fieldbus unset
Expansion Unit 1 Uninstalled
(Standard IO)
MFC-DT
Installed
(Expansion IO)
MFC-CC Installed
(CC-Link)
MFC-DN
Installed
(DeviceNet)
MFC-PB Installed
(PROFIBUS
DP-V1)
MFC-PN Installed
(PROFINET IO)
MFC-EN Installed
(EtherNet/IP)
CC-Link V1
CC-Link V2
