Chapter 6 Description of Operations
PAGE 6-50
D-No.400 CF Card Storage Capacity [%]
The storable capacity of the CF card is indicated.
D-No.401 RS232C-2 Communication Speed [bps]
The communication speed of the RS232C-2 interface is indicated.
D-No.402 RS232C-2 Parity
The parity of the RS232C-2 interface is indicated.
D-No.403 RS232C-2 Stop Bit [bit]
The stop bit of the RS232C-2 interface is indicated.
D-No.404 RS232C-2 Data Length [bit]
The data length of the RS232C-2 interface is indicated.
D-No.405 Not use
D-No.406 Not use
D-No.407 Not use
D-No.408 Not use
D-No.409 ID Input Selection
The selected ID input method is indicated (Fieldbus/RS232C-2).
