Chapter 6 Description of Operations
PAGE 6-72
D-No.546 Reverse Ramp Up Time [msec] Setting range: 100~5000, Standard setting: 500
The time constant for acceleration from zero speed to the maximum rotation speed of the tool in
reverse rotation operation is set. The reverse ramp up time is used in the following cases.
・Manual reverse by raising (“OFF”￫”ON”) of the PLC I/O input signal “REVERSE.”
・This is the reverse ramp up time used in D-No. 002 [Fastening Option]: “Reverse before Fastening.”
・This is the reverse ramp up time used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 1-2 Steps
ON.”
・This is the reverse ramp up time used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 2-3 Steps
ON.”
D-No.547 CCW Wait Time Between Steps [msec]
Setting range: 0~500, Standard setting: 200
This is the waiting time during which operation is stopped when normal rotation changes to reverse
rotation and vice versa when fastening is interrupted by a reverse rotation operation.
・This is the reverse wait time used in D-No. 002 [Fastening Option]: “Reverse before Fastening.”
・This is the reverse wait time used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 1-2 Steps ON.”
・This is the reverse wait time used in D-No. 006 [Fastening Interrupt Operation]: “Reverse Between 2-3 Steps ON.”
