Chapter 8 Options
PAGE 8-5
When the remaining capacity of the memory card falls to no more than 1%, the CF ACCESS LED
lights up in orange. The storable capacity of the memory card can be checked from the indicator.
●Procedures for Confirming the Storable Capacity of the Memory Card
1. Put the controller in a state in which starting by external control will not be performed and then
perform the following in the state where the I/O output signal: READY is “ON.”
2. Use the “◄” and “►” switches of the controller indicator to make the System Setting Mode be
indicated.
3. Use the “▲” and “▼” switches of the controller to make “400” be indicated at the COUNT/D-No.
indication part.
4. The value indicated at the upper stage of the indicator is the storable capacity (units: %) of the
memory card.
・ When the storable capacity of the memory card falls to no more than 0.1%,
storage into the memory card is discontinued to prevent mismatch of the
stored contents of the fastening results and the fastening curves (the CF
ACCESS LED lights up in red).
