48
SS2000+ Hotkey Activation
SS2000+ Series C
Federal Signal www.fedsig.com
Computer Mode
Requesting Reports and Polling
Any poll requests or activation commands from Commander software are examined by
the SS2000+ for time and date. The SS2000+ updates its internal clock to match, and
then sends the Digital message.
When Commander sends a poll request, the SS2000+ LCD displays the following.
Requesting Report:
Site# 001
REPORT STANDBY
The resulting reports are logged and sent to the Commander software. Incoming DTMF
messages are converted to Digital format, logged, and sent to Commander as well. These
transmissions are not acknowledged by the SS2000+.
Streaming Mode
In computer mode, the SS2000+ can also receive streamed audio/encode data from
Commander software and transmit it out as audio.
When the SS2000+ is transmitting streamed audio encode data, the SS2000+ LCD
displays the following:
Streaming Audio
Encoding
You can program up to three codes under each of 60 activation functions. These can be
as follows:
Two-Tone/Single-Tone codes
• 282 Hz to 3000 Hz, Timing, 0.5 sec min to 8 sec max
DTMF codes up to 16 characters
• 35 ms/5 ms to 100 ms/100 ms timing
Federal Signal one-way Digital Codes
• 1 to 255 Individual site, 300=All Call, 1 to 16 for zones 1 to 16
• 1 to 512 Individual site, 800=All Call if extended site numbers are used
• Function Number 1 to 50, 97=Cancel, 98=Quiet Test, 99=Reset
