Feig Electronic TST FU3F-A - Overview of Controller Outputs

TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 56 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
5.10 Overview of outputs
OUT1
Door is OPEN
OUT2
Door is
CLOSE
M
3~
T1
T2
T3
U
V
W
P
E
P
E
1
0
1
1
1
2
2
0
2
1
2
2
OUT3
Break
3
0
3
1
3
2
3
3
3
4
K1 NO
K1 Com
K1 NC
K2 NO
K2 Com
K2 NC
K3 NO
K3 Com
K3 NC
-24 VDC
+24 VDC
OUT4
24 VDC
Break
2,5 A
3
5
3
6
3
7
green traffic light - Output 28
red traffic light - Output 29
GND
24 VDC
Max.
700 mA
Figure 32: Overview of outputs
Observe maximum voltage and power specifications (see technical data
"Control voltage / external supply" or "Relay outputs“ on page 106 or 109).
Different to the standard mentioned here, the function of the outputs is freely selectable.
