MOD MC PREMIUM PM
B
DO NOT FULLY
REMOVE
0,5
0,5
A
2.2.8.2.2
The CDL is delivered adjusted but if it needs further adjustment, please follow the indications below according to
your case.
AIM
To carry on a ne tuning it’s only needed to loose the ve To carry on a ne tuning it’s only needed to loose the ve
indicated screws without fully remove it. The clutch base hole, indicated screws without fully remove it. The clutch base hole,
grants to move ± 7,5 mm.grants to move ± 7,5 mm.
If the regulation needed is more than ± 7,5 mm, you’ll need to fully If the regulation needed is more than ± 7,5 mm, you’ll need to fully
remove the screws with the aim to change their position in the remove the screws with the aim to change their position in the
carriage. (Except two screws placed in the carriage long hole).carriage. (Except two screws placed in the carriage long hole).
2.2 ASSEMBLY INSTRUCTIONS
2
2.2.8.2 CDL / CLUTCH ADJUSTMENT
